High performance thermally efficient double glazing, the inner pane of glass is upgraded with a specialist laminated interlayer making it much more difficult for potential intruders to gain entry via the rooflight.
All control electronics, mechanisms and power supply are completely hidden within the framework. Clean lines and clear views in and out.
Anti-slip tread plate design incorporated into threshold monitored by safety sensors to stop the rooflight should something be in the way.
Excellent thermal performance: U-value of 1,2 W/m²K.
Glasspecification: 32mm
Outer: 6mm HST Toughened
Spacer: 20mm Argon filled cavity with warm edge spacer bar
Inner: 8mm HST Toughened soft coat low E (1.1)
Important information
Upstand – Minimum 200 mm wide/150 mm high (by others)
Recommended pitch – Minimum 3 degrees / maximum 10 degrees
The units are hinged on the longest length.
Hinge should always be at the top of the fall
Colour – RAL7015 Slate Grey outer/ RAL9010 Pure White inner
Dimensions
A Skydoor XXL access hatch of 1.3 x 3.4 meter has the following dimensions
1300mm x 3400mm: overall weathered kerbs
900mm x 3000mm: inner dimension
1348mm x 3448mm: frame dimension
Quick and easy to install
All rooflights are designed to be easily installed by tradesmen or DIY enthusiasts.
